110V Offline UPS
SHANGYU POWER CHINA is one of the professional 110V Offline UPS manufacturers and suppliers in China, providing easy-maintainable and durable 110V Offline UPS worldwide. Not only do we have our own factory, but we also offer competitive prices. Our products have obtained CE certification, and we also provide customized services. You are welcome to place an order.
Send InquirySHANGYU POWER CHINA® 110V offline ups is the latest invention of high-quality ups products, which comply with CE, ROHS, IEC, BS,UL,TUV, SAA standard and comes with a 2-year warranty. As a professional manufacturer of UPS and precision air conditioner, Our aim is continuously to offer our customer stable and reliable, clean and high-efficiency power.welcome to inquiry.
SHANGYU POWER CHINA® 110V offline ups
You can rest assured to buy 110V Offline UPS from our factory. The SHANGYU POWER CHINA® 110V offline ups is made of metal+ PCBA, which has been designed to meet most demanding power requirements, being easy to install and maintain. It combines latest high energy efficiency technology and high power density technology, achieving small size, stable performance and price competitive for UPS products.
SHANGYU POWER CHINA® S series 110V offline ups Parameter (Specification)
| SPECIFICATIONS | S500/S550 | S600/S650 | S650B | S800/S850 | S1000 | S1500 | S2000 | S2000B | S3000 |
|---|---|---|---|---|---|---|---|---|---|
| Capacity | 500VA/300W | 600VA/360W | 650VA/390W | 800VA/480W | 1000VA/600W | 1500VA/900W | 2000VA/1200W | 2000VA/1200W | 3000VA/1800W |
| INPUT | — | ||||||||
| Voltage | 110/120VAC or 220/230/240VAC | ||||||||
| Voltage Range | 81-145VAC or 145-275VAC | ||||||||
| Frequency Range | 50Hz or 60Hz(auto-sensing) | ||||||||
| OUTPUT | — | ||||||||
| Output Voltage | 110/120 VAC or 220/230/240 VAC | ||||||||
| AC Voltage Regulation(Batt. Mode) | ± 10% | ||||||||
| Frequency Range(Batt. Mode) | 50 HZ or 60 Hz ± 10% | ||||||||
| Transfer Time | Typical 6-10 ms | ||||||||
| Waveform( Batt. Mode) | Simulated sine wave | ||||||||
| BATTERY | — | ||||||||
| Battery Type & Number | 12V/4AH×1 | 12V/7.5AH×1 | 12V/9AH×1 | 12V/7.5AH×2 | 12V/9AH×2 | 12V/9AH×2 | 12V/7.5AH×4 | 12V9AH×4 | |
| Typical Recharge Time | 8 hours recover to 90% capacity | ||||||||
| PROTECTION | — | ||||||||
| Full Protection | Short Circuit,Over load, Battery Low Voltage protection and off-mode charging | ||||||||
| RS232 or USB communication port | Optional | ||||||||
| RJ11/RJ45 port | Optional | ||||||||
| INDICATORS | — | ||||||||
| Line Mode | Green lighting | ||||||||
| Battery Mode | Red lighting | ||||||||
| Battery Charge Mode | Yellow lighting | ||||||||
| ALARM | — | ||||||||
| Battery Mode | Sounding every 10 seconds | ||||||||
| Low Battery | Sounding every second | ||||||||
| Overload | Sounding every 0.5 second | ||||||||
| Fault | Continuously sounding | ||||||||
| ENVIRONMENT | — | ||||||||
| Humidity | 0-90% RH @ 0-40℃(Non-condensing) | ||||||||
| Noise Level | Less than 40dB | ||||||||
| PHYSICAL | — | ||||||||
| Dimension, D×W×H(mm) | 265×90×137 | 307×90×137 | 307×90×137 | 320×100×150 | 365×138×165 | 365×138×165 | 365×138×165 | 390*145*210 | 390*145*210 |
| Net Weight(kgs) | 4 | 5 | 5.2 | 6.2 | 9 | 11 | 12 | 17 | 21 |
SHANGYU POWER CHINA® 110V offline ups 500-3000VA Feature And Application
KEY FEATURES
* Line-interactive UPS with super-long backup time
* wide input range with AVR function
* Protection for short circuits, overloads, and battery low voltage
* LED indication and audible alarm function
* Intelligent battery management
* with cold start function
* with AUTO restart function
* Automatic battery charging while UPS is off(Optional)
* USB+RJ11/RJ45 or RS232 port(optional)
Application|: PC, Work station, Small communication equipment.
SHANGYU POWER CHINA® 110V offline ups 500-3000VA Details
When compare with peers, SHANGYU POWER CHINA® 110V offline ups 500-3000VA advantages as below:
| Model No. | 1Pallet | 20GP | 40GP | 40HQ | Remark |
|---|---|---|---|---|---|
| S500 | 128 | 1280 | 2688 | 4032 | 192pcs max. |
| S650B | 128 | 1280 | 2688 | 4032 | 192pcs max. |
| S800 | 96 | 960 | 2016 | 2520 | 120pcs max. |
| S1000-2000 | 64 | 640 | 1344 | 1680 | 80pcs max. |
| S2000B/3000 | 48 | 480 | 1008 | 1176 | 56pcs max. |
